XHF-01B Automatic Fabric Air Permeability Tester is used to test the air permeability of various woven fabrics, knitted fabrics, non-woven fabrics, industrial filter materials etc.
AFNOR G07-111, ASTM D 737, ASTM D 3574, BS 5’636, EDANA 140.1, DIN 53887, EDANA 140.1, EN ISO 7231, EN ISO 9237, JIS L 1096-A, TAPPI T 251, WSP 70.1
Wide measuring range of 0.8-14000mm/s at 20 cm² test area
Wide test pressure range of 1-2,400 Pa
Fast and simple sample pneumatic clamping test samples with a high percentage of side air.
LargeTouch screen control display for digital and graphic display of the test result.
Self-designed muffler to control the suction fan, quiet and mobile instrument, perfectly suitable for use in the laboratory and in the production area.
Adopt high precision imported sensor, test results is accurate.
Equip with standard calibration plate to calibrate machine quickly.
Automatic cleaning function of the orifice provides for stable test results.
Optional integrated software for evaluation and storage of the test results in XML format.
Works in accordance with all major test standards.
Fast test speed, can get test results within 30 seconds.
Test Pressure Range | 1-2400Pa |
Permeability ratio range | 0.8-14000mm/s at 20 cm² test area |
Specimen thickness | ≤8mm |
Measuring accuracy | ≤±2% |
Test area (Standard) | 20 cm2 |
Test Area (Optional) | 5cm2, 25cm2, 38.3 cm2, 50cm2, 100cm2 |
Test Units | mm/s, cm3/cm2/s, L/dm2/min, m3/m2/min, m3/m2/h, d m3/s, cfm |
Calibration | Unique Calibration Board |
Communication Interface | USB |
Dimension | 550x900x1200mm |
Gross Weight | 105kg |
Power source | 110V/220V, 50/60Hz |
